P6.67 mm Outdoor Waterproof Front and back Service LED Display
Module
Product Features
1. Front and back service makes maintenance quick and easy. High
efficient Led lamps save energy
maxi and achieve get protection accordingly
2. Special PCB design with low current to save energy more than
30%. Selected small tolerance
wavelength led lamps ensure higher uniformity
3. Good quality led chip with lower led attenuation, best color
uniformity, lower default rate and long lifespan
SPECIFICATION OF C6.67 Outdoor Front Service LED Display
| Model | C6.67 |
| Pixel pitch(mm) | 6.67 |
| LED lamp | SMD 2727 |
| Module size(mm) | 320 x 320mm |
| Module weight(kg) | 1.5kg |
| Cabinet size(mm) | Customized |
| Pixel density(dots/㎡) | 22477 |
| Flatness error(mm) | ≤0.2 |
| Viewing angle | 140°/140°(Horizontal/Vertical) |
| Brightness(cd/㎡) | 8000 nits |
| Color temperature(K) | 6500~9500 (Adjustable) |
| Contrast | 5000:1 |
| Repetition frequency | 50/60Hz |
| Refresh frequency(Hz) | ≥1920 Hz |
| Gray scale | 16bit |
| Ave. power(W/㎡) | 950 |
| Max power(W/㎡) | 450 |
| Working temp./humidity | -10~40℃/10%~80%RH |
| Storing temp./humidity | -20~60℃/10%~85%RH |
| Cabinet material | Aluminum |
| Maintenance | Front and back maintenance |
| Protection | IP65/IP65 |
| Driving mode | Constant current driver |
| Scanning | 6S |
| Power requirements | AC90~264V |
| Life time(hrs) | 100,000 |
Advantages OF C6.67 Outdoor Front Service LED Display
1. Front Service Design: Unlike traditional front service design
with hydraulic pipes, which cost more on
project and with low IP rating due to the conjunction of structure.
C6.67 LED Sign is like normal cabinet
design, but bigger size. The IP rating can reach to IP65. All the
modules, cards and power supply can be
maintained from front. The whole sign can be attached to the wall
and no need maintenance space at
back
2. Convenient Sign Design, Easy to Install: C6.67 LED Sign is
easier to install, not picked on installation
environment. Most structure frames are integrated on the sign, no
complicated steel structure needed, just
fix the sign to the pole or to the wall. Extremely save
installation time and labor cost
3. Higher IP Rating, Perfect For Outdoor Advertising: Thanks to
special waterproof cabinet structure (no
rear doors), C6.67 sign screen can be IP65 waterproof. Aluminum
material and ventilation design
make sure perfect cooling effect. All these key features are
critical for outdoor commercial advertising
activities. No matter it is a small size LED screen or a huge
commercial LED billboard, C6.67 will present
you the trustworthy quality and high profile screen performance
Benefits of Lecede C6.67 Outdoor Front Service LED Display
C6.67 integrated front service led signs advertising solution with
light sensors, temperature sensors,
asynchronous control cards, which support Wireless and wire control
ways. Our front service cabinet sizes
can be customized freely. And you don't need to worry about the
installation structure, we provide you soft
solutions which enable you to hanging or fixing.
