Big Transparent Glass LED Display SMD 3535 , 1R1G1B P10 Transparent
Led Video Wall
Description:
1. Lightweight & Super Thin
Made by good aluminum material, one panel only weights 12.5 KG. It
enables the installation job and
delivery job very comfortable and convenient. Thin thickness not
only saves space for delivery but also for
installation environment.
2. High brightness & Waterproof
Brightness reaches 6000nits, Waterproof IP65. The product can be
used for indoor and outdoor.
3. Angle Adjustment
Cabinet connection angle can be adjusted by -15 degree to +15
degree. You can shape the LED panel as
arc shape.
4. Fast Lock System & No Fan Design
Fast lock system design enables the installation faster and easier.
An average worker can complete 50-70
panels within one hour. Nature cool design generates better
dissipation and less power consuming.
5. Comprehensive Usage
With Above features, the product can be used for multi purposes:
rental and fix installation, events, trade
show etc.
Applications:
Rental, Advertising, Stage, Events, Show, Exhibition,
Entertainment, Concerts
Quick Detail:
1. Lightweight :< 12.5KG/panel. Ultra thin: 100mm thickness
2. High brightness: more than 6000cd/㎡
3. Waterproof Level: IP65(Front Side), IP54 (Back Side)
4. CE,CCC,RoHS,UL,ISO9001
5. Made by good aluminum material
6. Cabinet connection angle can be adjusted by -15 degree to +15
degree
Outdoor IP65 P10 Transparent LED Screen , Ultra Thin LED Display
Specifications:
1. T10 Technical Parameter
| Model No. | T10 |
| Pixel Pitch | 10mm |
| Module Resolution (W*H) | 100 dots*10 dots |
| Pixel Density | 10000 dots/ ㎡ |
| LED Type | SMD 3535 |
| Pixel Configuration | 1R1G1B |
| Wavelength (R.G.B) | R:625±2nm G:525±2nm B:470±2nm |
| Drive Mode | Dynamic 1/6 Duty Constant Current |
| Cabinet Size | 1000×1000×100mm |
| Cabinet Resolution | 40dots×80dots |
| Brightness | ≥6000cd/㎡ |
| Contrast | ≥2000:1 |
| Viewing Angle | 140°(Horizontal )/140°(Vertical ) |
| Best Viewing Distance | 7m-300m |
| Grey Scale | 10bits/1024levels |
| Color Capability | 16777216 |
| Color Temperature | 5000-9300K |
| Maximum Power Consumption | 1200W/m2 |
| Average Power Consumption | 600 W/m2 |
| Working Voltage | AC 220V/110V s±15% 50-60 HZ |
| Frame Frequency | 60-85 HZ |
| Refresh Frequency | 240 - 1000HZ |
| Brightness Correction | Pixel, Module, Cabinet Correction |
| Operating Temperature | -40~+65℃ |
| Operating Humidity | 10-90% RH |
| LED Lifespan | 100,000 hours |
| MTBF | ≥50,000 hours |
| Computer Operation System | Win 98/ Win XP/ Win 2000 |
| Video Signal Input | RF,S-Video, RGB,RGBHV,YUV,YC,VGA, DVI, HDMI, SDI,HD-SDI ,Composite |
| Video Signal Output | RF, S-Video, RGB, RGBHV, YUV, YC etc. |
| Graphics Card | DVI Graphics Card |
| Control Distance | LINSN / NOVA / DB-STAR |
| Software | LED studio 10.0 |
| Waterproof Level | IP65(Front Side), IP54 (Back Side) |
| Installation | hung and stand |
| Out of Control Rate | 0.01 % |
4. Methods for Quality Assurance
a. aging
1. 100% fully test
2. Condition: 72 hours with 256 grey level
b. Vibration Testing
Condition: 3-5 mins up and down in 5mm range
5. Factory Equipment
Wave Soldering Conveyor, PC Console, Wave Soldering Machine,
Automatic Glue- pouring Machine, Solder Paste Printing Machine,
Reflow Soldering Machine, Automatic Solder Paste Printing Machine,
Withstand Voltage Tester, Ground Resistance Tester,
Medium-speed Automatic SMT Machine, Super Mute Terminal Machine,
Automatic Wire Stripping Machine, Automatic Optical Inspection
(AOI) Equipement.
6. Package
Flight case or Fumigation-Free wooden case
7. Control System Connection
8. Competitive Advantage:
1. 24/7 Online support service
2. Free onsite maintenance / Year
3. Solution design
4. Free online training any time
5. High quality raw material used like Neutrik flight connector,
MBI IC etc.
