P16 / P33 LED Curtain Screen For Outdoor Advertising Large Viewing Angle

    Buy cheap P16 / P33 LED Curtain Screen For Outdoor Advertising Large Viewing Angle from wholesalers

    Buy cheap P16 / P33 LED Curtain Screen For Outdoor Advertising Large Viewing Angle from wholesalers
    • Buy cheap P16 / P33 LED Curtain Screen For Outdoor Advertising Large Viewing Angle from wholesalers
    • Buy cheap P16 / P33 LED Curtain Screen For Outdoor Advertising Large Viewing Angle from wholesalers

    P16 / P33 LED Curtain Screen For Outdoor Advertising Large Viewing Angle

    Ask Lasest Price
    Brand Name : Lecede
    Model Number : LED Curtain Screen
    Certification : CE ROHS FCC UL ETL
    Price : Negotiation
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 10000 ㎡/month
    Delivery Time : 15~30 days after deposit
    • Product Details
    • Company Profile

    P16 / P33 LED Curtain Screen For Outdoor Advertising Large Viewing Angle

    P16 / P33 LED Curtain Screen For Outdoor Advertising Large Viewing Angle


    Specification:


    ModelLC16LC33
    Pixel pitch (mm)16.633.33
    Resolution(Pixels)30 x 6015 x 30
    EncapsulationDIP346 LED
    Configuration1R1G1B2R2G2B
    Panel dimension(mm)500 x 1000
    Panel weight(kg)87.5
    Pixel density(dots/㎡)36009000
    Flatness error(mm)≤0.1
    Viewing angle(°)110/50(Horizontal/Vertical)
    Brightness(cd/㎡)65006500
    Color temperature(k)6500
    Recommended viewing distance(m)15 - 10030 - 250
    Contrast4000:1
    Repetition frequency(Hz)50/60
    Refresh frequency(Hz)1920
    Gray scale(bit)16
    Max power(W/㎡)240225
    Working temp./humidity-10~50℃/10%~90%RH
    Storing temp./humidity-20~60℃/10%~90%RH
    ProtectionIP65/IP65
    Power requirementsAC 220V
    Signal Transmission DistanceCAT cable:<100m;Single mode fiber:<10km
    Installation wayFix / Front and rear maintenance, no tools needed
    Life time(hrs)100,000
    CertificateCCC/TUV-CE/ETL, etc.

    Advantage:


    1. Brightness uniformity less then 5%, and the maximum uniformity can reach 1%


    2. On line pixel inspection function : inspect each disabled pixel and remote transmission


    3. Automatic brightness adjustment: adjust the brightness of the screen according to the ambient


    brightness, thus avoiding the waste of brightness and reducing power consumption


    4. Large horizontal and vertical viewing angle


    5. Led module can remain constant in the hight and low temperature environment


    6. Gray scale of 16 bits, and contrast of 1000:1


    Features:


    1. Completely transparent material, Cool display effect.


    2. Rich installation accessories, flexible installation, adapting to different scenarios.


    3. A creative way to realize the ultra-thin double display and the thickness of whole screen is not more than 33 mm.


    4. The rhombus display without additional parts creates the dreamlike effect for the world.


    5. High permeability, go through light, air and smoke easily.


    6. Realizing various irregular shapes without considering the restrictions of scenario.


    Service:

    1. Your enquiry will be replied in 24 working hours.
    2. Experienced staffs answer all your query in fluent English.
    3. Customized design is available,OEM & ODM are welcomed.
    4. Exclusive and unique solution can be provided by our well-trained and professional engineers
    and staffs.
    5. Area distributor enjoys special discount and protection of sales area.
    6. Your visit will warmly welcome in anytime.
    7. 2 Years guarantee. Only charge for cost of repair after 2 years.
    8. Lecede assists with trainning and technical support for clients in the factory. This service is
    free of charge.
    9. Lecede offers oversea technical support by well-trained engineers if clients required. The
    relevant costs charge by clients.

    P16 / P33 LED Curtain Screen For Outdoor Advertising Large Viewing Angle
