    10MM Pixel Pitch Outdoor Advertising LED Display Screen P10 SMD High Brightness

    Ask Lasest Price
    Brand Name : Lecede
    Model Number : Q10
    Certification : CE ROHS FCC UL ETL
    Price : Negotiation
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 10000 ㎡/month
    Delivery Time : 15~30 days after deposit
    • Product Details
    • Company Profile

    10MM Pixel Pitch Outdoor Advertising LED Display Screen P10 SMD High Brightness


    Outdoor Advertising LED Display Screen P10 SMD High Brightness


    Product Features

    1. The first level LED chip from Taiwan Epistar


    2. With pure golden wire connection in LED


    3. Ag alloy solder paster to ensure good soldering on PCB


    4. Stainless steel screws when assembly


    SPECIFICATION OF Q10 Outdoor Advertising LED Display Screen


    ModelQ10
    Pixel pitch(mm)10
    ConfigurationSMD3535
    Module dimension(mm)320x160
    Module weight(kg)0.5
    Cabinet dimension(mm)960x960x120
    Pixel density(dots/㎡)10000
    Flatness error(mm)≤0.1
    Viewing angle140°/140°(Horizontal/Vertical)
    Brightness(cd/㎡)7000
    Color temperature(K)5000~9500 (Adjustable)
    Contrast4000:1
    Repetition frequency50/60Hz
    Refresh frequency(Hz)1920
    Gray scale65536
    Ave. power(W/㎡)430
    Max power(W/㎡)850
    Working temp./humidity-10~40℃/10%~80%RH
    Storing temp./humidity-20~60℃/10%~85%RH
    Cabinet materialIron/Aluminum
    MaintenanceRear
    ProtectionIP65/IP65
    Driving modeConstant current driver
    Scanning1/2
    Power requirementsAC90~264V, 47~63Hz
    Life time(hrs)100,000
    CertificateCE ROHS FCC UL ETL, etc.

    Advantages of Lecede Q10 Outdoor Advertising LED Display Screen


    1. Lecede Q10 can do error detection and monitoring: it can monitor the inner temperature, voltage,


    cooling fans etc and make error detection automatically.


    2. The brightness of Lecede Q10 is adjustable to meet the need of changing environment.


    3. Lecede Q10 has wide viewing angle: The horizontal and vertical viewing angles are so wide that it is


    suitable for wide horizontal.


    4. Lecede Q10 is environment protection, antistatic, dust-proof, good heat dissipation, cost-effective.


    Benefits of Lecede Q10 Outdoor Advertising LED Display Screen


    Lecede Q10 outdoor advertising LED display screen has many benefits. First of all, the image of our Q10


    outdoor LED screens is extremely clear and furthermore the vivid colours ensure that your adverts pop


    out and come to life! Another benefit is that the content can be easily adjusted to any situation with our


    user-friendly software. Reliable in practically all weather conditions, from polar cold to desert heat.
